Fastech Ezi-SERVO ST User Manual

www.fastech-motions.com - 28
16. Settings and Operation
◆ 86mm Motor Drive (EzS-PD-86 series)
Pulse input and direction setting switch(SW1)
Position controller gain setting switch(SW2)
Resolution setting switch(SW3)
In-Position value setting switch(SW4)
Encoder connection(CN2)
Motor connection(CN3)
Power connection(CN4)
Pulse input and direction setting switch(SW1)
Position controller gain setting switch(SW2)
Resolution setting switch(SW3)
In-Position value setting switch(SW4)
Encoder connection(CN2)
Motor connection(CN3)
Power connection(CN4)
Drive status LED
Drive status LED
Input/Output signal connection(CN1)
Input/Output signal connection(CN1)
