FASTRON. VC-210 Installation And Operating Instructions

Process Controllers
FAST Lit. Part No. 229-51317 Rev. B (EMPLOYEE) 11/01/2007 (L20-321 rev 0 12/07) Page 2
© 2005-2007 Food Automation – Service Techniques, Inc. All Rights Reserved
This document contains confidential information. The dissemination, publication,
copying, or duplication of this document without prior written authorization is
strictly prohibited.
Installing the (FASTRON.) VC-210
Controller
REMOVE EXISTING (FASTRON.)
1
Unplug fryer
2
Remove the two (2) screws from the bezel securing the (FASTRON.) controller in the
header cavity. Remove the bezel.
3
Remove the controller by disconnecting the 9-pin and 2-pin connectors. (Several pressure
and split vat fryers will have additional connectors that will have to be removed.)
INSTALL THE NEW (FASTRON.)
1
Remove the two (2) 5/32” screws from the NEW controller.
2
Plug the 9- and 2-pin connectors into the corresponding connectors in the fryer. (Several
pressure and split vat fryers will have additional connectors that will have to be connected.)
NOTE: The 3-pin connector coming from the controller has no corresponding connector. It
is for future use.
3
Insert the controller back into the fryer header cavity. Re-attach the bezel (frame) to the
controller.
4
Secure the controller and bezel to the fryer header with the two (2) 5/32” hex screws
provided.

FASTRON. VC-210 Specifications

General

Brand	FASTRON.
Model	VC-210
Category	Controller
Language	English
