Fatar TP/9S - CONNECTORS

TP/9S 6509xxxx
CONNECTORS
Connector: Tyco/AMP Micro-Match
Type: Female-On-Board
Mount Angles: Vertical
A
A: distance between connectors
A = 54,7 mm
Pin:
• 25 notes: 1x 20vie
• 37 notes: 1x 20vie
• 44 notes: 1x 20vie
• 49 notes: 2x 16vie
• 61 notes: 2x 16vie
• 76 notes: 1x 16vie + 1x 20vie
