FATEK FBe-28MC - Page 43

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
43
4A)
• 1:1 Connection
• 1:n Connection
Signal name
RDB
SDB
SG
FG
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Display
Terminal block
RDA
SDA
User-created Cable
Shield
External Device
Terminal block
Signal name
D+
D-
FG
TERM
Terminal resistance: ON
Signal name
RDB
SDB
SG
FG
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Display
Terminal block
RDA
SDA
User-created Cable
Shield
External Device
Terminal block
Signal name
D+
D-
FG
TERM
Terminal resistance: OFF
Shield
External Device
Terminal block
Signal name
D+
D-
FG
Terminal resistance: ON
