FATEK FBe-28MC - Communication Setup; GP-Pro EX Setup Examples

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
9
3 Example of Communication Setting
The following shows examples of communication settings for the Display and the External Device, which are
recommended by Pro-face.
3.1 Setting Example 1
 Settings of GP-Pro EX
 Communication Settings
To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].
 Device Setting
To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]
window, select the external device and click [Settings] .
To connect multiple External Devices, from [Device-Specific Settings] in the [Device/PLC] window, click [Add
Device] to add another External Device.
 Settings of External Device
The communication setting is fixed.
