FATEK FBe-28MC - Device Code and Address Code

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
85
7 Device Code and Address Code
Use device code and address code when you select "Device Type & Address" for the address type of the data
display or other devices.
Device Device Name
Device Code
(HEX)
Address Code
Input Relay X/WX 0082
Value of word address divided by
16
Output Relay Y/WY 0083
Value of word address divided by
16
Step Relay WS 0084
Value of word address divided by
16
Internal Relay WM 0085
Value of word address divided by
16
Special Relay WSM 0086
Value of (word address - 1912)
divided by 16
Timer (Current Value) TMR 0060 Word Address
Counter (Current Value) CTR 0061 Word Address
High-speed Counter HC 0062 Word Address
Data Register HR 0000 Word Address
Data Register R 0080 Word Address
Data Register D 0081 Word Address
Input Register IR 0001 Value of (word address - 3840)
Output Register OR 0002 Value of (word address - 3904)
Special Register SR 0003 Value of (word address - 3968)
HSC Register HSC 0004 Value of (word address - 4096)
Calendar Register RTC 0005 Value of (word address - 4128)
HST Register HST 0008 Value of (word address - 4152)
Read-only Register ROR 0006 Value of (word address - 5000)
File Register F 0007 Word Address
