1.4 List of FBS PLC Models
Item Name Model Number Specifications
FBS-20MN□◇Δ–◎
2 points 7920KHz 5VDC differential input, 10 points 24VDC digital input (20KHz), 2 points 7920KHz
5VDC differential output, 6 points (R/T/S) digital output (Model “T” 6 points 20KHz output), 1 RS232
or USB port (expandable up to 5), built-in RTC, detachable terminal block
FBS-32MN□◇Δ–◎
4 points 920KHz 5VDC digital differential input, 16 Points 24VDC digital input (20KHz for 12 Points),
4 points 7920KHz 5VDCdigital differential output, 8 Points (R/T/S) digital output (Model “T” 4 Points
20KHz output), 1 RS232 or USB port (expandable up to 5), built-in RTC, detachable terminal block
NC Control
Main Unit
FBS-44MN□◇Δ–◎
8 points 7920KHz 5VDC digital differential input, 20 Points 24VDC digital input (20KHz for 8 points),
8 points 7920KHz 5VDCdigital differential output, 8 points (R/T/S) digital output (Model “T” 4 Points
20KHz output), 1 RS232 or USB port (expandable up to 5), built-in RTC, detachable terminal block
FBS-10MC□◇Δ–◎–XY
6 points 24VDC digital input (2 points 100KHz＋4 points 20KHz), 4 points (R/T/S) digital output
(Model “T” 2 points 100KHz＋2 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC, I/O is not expandable
FBS-14MC□◇Δ–◎–XY
8 points 24VDC digital input (2 points 100KHz＋6 points 20KHz), 6 points (R/T/S) digital output
(Model “T” 2 points 100KHz＋4 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC, I/O is not expandable
FBS-20MC□◇Δ–◎–XY
12 points 24VDC digital input (2 points 100KHz＋10 points 20KHz), 8 points (R/T/S) digital output
(Model “T” 2 points 100KHz＋6 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC
FBS-24MC□◇Δ–◎–XY
14 points 24VDC digital input (2ppoints 100KHz＋12 points 20KHz), 10 points (R/T/S) digital output
(Model “T” 2 points 100KHz＋6 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC, detachable terminal block
FBS-32MC□◇Δ–◎–XY
20 points 24VDC digital input (2 points 100KHz＋14 points 20KHz), 12 Points (R/T/S) digital output
(Model “T” 2 points 100KHz＋6 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC, detachable terminal block
FBS-40MC□◇Δ–◎–XY
24 points 24VDC digital input (2 points 100KHz＋14 points 20KHz), 16 points (R/T/S) digital output
(Model “T” 2 points 100KHz＋6 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC, detachable terminal block
Advanced
Main Unit
FBS-60MC□◇Δ–◎–XY
36 points 24VDC digital input (2 points 100KHz＋14 points 20KHz), 24 points (R/T/S) digital output
(Model “T” 2 points 100KHz＋6 points 20KHz output), 1 RS232 or USB port (expandable up to 5),
built-in RTC, detachable terminal block
FBS-10MA□◇Δ–◎
6 points 24VDC digital input (up to 10KHz in 4 points), 4 Points (R/T/S) digital output (Model “T” has
4 points 10KHz output), one RS232 or USB port (can be expanded up to 3), I/O is not expandable
FBS-14MA□◇Δ–◎
8 points 24VDC digital input (up to 10KHz in 4 points), 6 points (R/T/S) digital output (Model “T” has
4 points 10KHz output), one RS232 or USB port (can be expanded up to 3), I/O is not expandable
FBS-20MA□◇Δ–◎
12 points 24VDC digital input (up to 10KHz in 4 points), 8 points (R/T/S) digital output (Model “T”
has 4 points 10KHz output), one RS232 or USB port (can be expanded up to 3)
FBS-24MA□◇Δ–◎
14 points 24VDC digital input (up to 10KHz in 4 points), 10 points (R/T/S) digital output (Model “T”
has 4 points 10KHz output), one RS232 or USB port (can be expanded up to 3)
FBS-32MA□◇Δ–◎
20 points 24VDC digital input (up to 10KHz in 4 points), 12 points (R/T/S) digital output (Model “T”
has 4 points 10KHz output), one RS232 or USB port (can be expanded up to 3)
FBS-40MA□◇Δ–◎
24 points 24VDC digital input (up to 10KHz in 4 points), 16 points (R/T/S) digital output (Model “T”
has 4 points 10KHz output), one RS232 or USB port (can be expanded up to 3)
Basic
Main Unit
FBS-60MA□◇Δ–◎
36 points 24VDC digital input (up to 10KHz in 4 points), 24 points (R/T/S) digital output (Model “T”
has 4 points 10KHz output), one RS232 or USB port (can be expanded up to 3)
Expansion
Power
FBS-EPOW-◎
Power supply for expansion module, with single 5VDC and dual 24VDC voltage output and up to
20VA capacity
FBS-24EAP□◇–◎ 14 points 24VDC digital input, 10 points (R/T/S) digital output, built-in power supply
FBS-40EAP□◇–◎ 24 points 24VDC digital input, 16 points (R/T/S) digital output, built-in power supply
Digital
Expansion Unit
FBS-60EAP□◇–◎ 36 points 24VDC digital input, 24 points (R/T/S) digital output, built-in power supply
FBS-8EA□◇ 4 points 24VDC digital input, 4 points (R/T/S) digital output
FBS-8EX 8 points 24VDC digital input
FBS-8EY□◇ 8 points (R/T/S) digital output
FBS-16EA□◇ 8 points 24VDC digital input, 8 points (R/T/S) digital output
FBS-16EY□◇ 16 points (R/T/S) digital output
FBS-20EX 20 points 24VDC digital input
FBS-24EA□◇ 14 points 24VDC digital input, 10 points (R/T/S) digital input
FBS-40EA□◇ 24 points 24VDC digital input, 16 points (R/T/S) digital output
Digital
Expansion
Unit
FBS-60EA□◇ 36 points 24VDCdigital input, 24 points (R/T/S) digital output
FBS-24EX 24 points high-density 24VDC digital input, 30-Pin Header with latch
Digital I/O Module
High-Density
Digital
Expansion
Module
FBS-24EYT 24 points high-density transistor Sink type digital output (0.1A max.), 30-Pin Header with latch
