Chapter 15 Synchronous Control, Flying Cut
1-3
M-Series PLC Motion User Manual
15-2 Synchronous Parameter Setting Group
Groups will be created for setting the synchronous parameters so that they will be classified
according to the designated group in helping the user find out the corresponding parameter.
A. Basic Setting
B. Initialization Setting
C. Master Axis 1 input
D. Slave Axis 2 Input
E. Master Axis Phase Offset
F. Variable Gear
G. Main Clutch
H. Step Angle Offset
I. Cam
J. Output Filter
