FAURE-HERMAN
COMPONENT MAINTENANCE MANUAL
744-082 / 744-082-3
28-49-91
PAGE 801/802
JULY 17/13
FITS AND CLEARANCES
1. EQUIPMENT REQUIRED
This section includes fits and clearances and tightening torque table.
The figure and item numbers in this chapter correspond with those of the ILLUSTRATED PARTS
LIST.
2. FITS AND CLEARANCES
Not applicable.
3. TABLE OF TIGHTENING TORQUES
CAUTION: THE NOMINAL VALUE TAKES INTO ACCOUNT THE MEASURE SCATTERS OF
THE TORQUE WRENCH USED (ACCURACY ±10 MAX.).
IPL REFERENCE TYPE
NOMINAL VALUE
N.m (lb.in)
4-125 Screw 0.2 0.005 (1.770 0.044)
