FAVERO Electronics - 0259-0902A Assioma user manual _Rev21 - EN-IT-DE
ENGLISH
8.2. Shoe position check
Thanks to its reduced dimensions, the sensor never comes into contact with the shoe
even when large size or at-soled footwear is worn.
Before starting to ride, check that the distance between the shoe and the sensor
is at least 2 mm. Do not use the product if the sensor is in contact with the shoe,
the shoe cover or the cleat, as it can be damaged and this would invalidate the
warranty.
If the distance between the sensor and the shoe is less than 2 mm, move the cleat to
the most appropriate position or insert spacer Art.771-45 between the cleat and the
shoe sole.
Cleat
≥ 2 mm
Shoe
Assioma
