Fine 0 – 127 Fine tuning of the selected trigger/
pad
Release 0 – 127 Release time
Volume 0 – 127 Pad volume
Tone 0 - 127 Tone setting of the selected
trigger/pad
Pan -63 - +63 Pan-tuning of the selected trigger/
pad
Reverb 0 - 127 Reverb-tuning of the selected
trigger/pad
MIX Settings Menu
The MIX settings menu includes parameters that have to do with the tone control of the internal module, as
well as the addition of effects like reverb.
The following parameters can be viewed and adjusted in the MIX settings menu:
Parameter Value Description
Equalizer ON/OFF Switch the internal equaliser on or
off
Low gain 0-127 Gain control for the lower
frequencies
High gain 0-127 Gain control for the higher
frequencies
Low freq 0-127 Level of the lower frequencies
High freq 0-127 Level of the higher frequencies
Reverb type 8 types Reverb type selection
Room size 5 types Room size selection. This effects
the sustain or ‘tail’ of the reverb
Reverb level 0 -127 Reverb level
Reverb time 0 – 127 Set the reverb-time
Reverb PreLF 0 – 7 Reverb PreLF range setting
Utility Settings Menu
The DDK-080 offers even more control over its settings and to make navigating the various menus more
comfortable, the Utility menu can be used to adjust the display screen, change the kick drum response, and
perform a factory reset.
In the Utility menu, the following sub-menus can be found:
- Brightness setting
- Kickdrum setting (digital trigger or mechanical kick)
- Factory reset
- DDK-080 module information
All information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 07-05-2020 RV Revision date + author initials:
