Specifications
Display Type
15.1” TFT Color LCD
Display Color
16.7 Million Colors
Screen Resolution
VGA 1024 x 768
Brightness
400 cd/m
2
Dimensions
14.14”(W)x11.95”(H)x2.5”(D)
Display Size
11.89”(W)x8.91”(H)
Weight
7lbs 5 oz
Power
28V DC @ 1.5AMPS
PC & Video Input
VGA (High Density DB-15 Connector),
Composite (4)
Video Type Supported
NTSC/PAL
Screen Control
On-Screen Display Menu
Materials
Aluminum
DO-160 Testing
Section 21, Category B
Remote Control
IR, included
Pixel Pitch
0.3mm x 0.3mm
Installation Instructions
All cabin entertainment equipment, such as the FD151CV-QUAD, should be installed on
a non-essential bus and have a dedicated circuit breaker. It is a requirement that a switch
be installed in the cockpit so that the pilot can de-energize the entertainment system
should it become necessary.
For mounting specifications refer to drawing at the back of the manual.
(NOTE: Removing the front cover does not void the warranty.)
When installed, at least ¼” gap should be maintained along the top and along the bottom
of the unit to allow for convection cooling.
Power
This is a 28VDC monitor that requires 1.5 AMPS (42 Watts) of power to operate. The unit
turns on automatically upon power application.
