Operation Instructions
The FD151CV-QUAD is continuously on but can be de-energized by removing power
from the entertainment system. No pilot or aircrew action is necessary during flight or
ground operation.
The passengers will be able to change the video output from the FD151CV-QUAD using
the video source select button on the display, or remotely throughout the cabin with the
included IR remote. Point the IR remote at the top of the LCD to make changes.
When applying 28VDC power, the display will turn on and look for a valid input on the
last known source. If no input is found, the display will go to standby mode. Pressing the
Select button will select new video input.
