Specifications
FDDOCAPSULE
Key Features
Video Output
VGA, HDMI 1.4
Audio Output
Stereo Line Level Output
File Types
Video: MP4 part 10/ H.264 Files
Audio: MP3
Pictures: JPEG
Media Storage
Space for 2 Removable SATA: (1) 1 Terabyte SSD included with this
product. (Media storage is only limited to amount of data the SSD
can store).
External USB: (2) USB 3.0, (2) USB 2.0
Network Connections
(2) 10/100/1000 Mbps
FMS/GPS Data Interface
ARINC 429 – 12.5Kb/s or 100Kb/s (Auto), RS-232
Power
Power
28VDC
Inrush Current
20.0 Amps Peak
2.0 Amps @ 50µS
1.0 Amps steady State @ 350µS
Operating Current
Typical: 1.1 Amps
Max: 2 Amps
Environmental
Conditions
Operating Temperature
-15 to +55° C
Dimensions
External
6.35”(W) x 1.95”(H) x 9.75”(D)
Weight
3 lbs. 4 oz.
Materials
Aluminum
Qualification
Testing
RTCA DO-160
Section 21 Category B – EMI
Section 4, Category A1 - Temperature Conditions
Section 8, Fixed Wing Category S, Zone 2, Curve M - Sine Vibration
Section 7, Category B – Operating Shock
Section 7, Category B - Crash Safety Shock
Section 26, Category C - Flammability (Vertical 12 Second Burn)
