b) Queue traffic
12
DIP-switch 8 "ON"
pulse signal
DIP-switch 8 "OFF"
permanent signal
Ð
1 2
Ð
12
Relay 1
Æ directional pulse
Relays 1
Æ permanent direction signal
'on'
Ð
1 2
Relay 1
Æ permanent direction signal
'remains'
Ð
1 2
Relay 1
Æ permanent direction signal
'remains'
Ð
1 2
Relay 1
Æ permanent direction signal
'off'
Ð
12
Relay 1
Æ directional pulse
Relay 1
Æ permanent direction signal
'on'
Ð
1 2
Relay 1
Æ permanent direction signal
'remains'
Ð
12
Relay 1
Æ permanent direction signal
'off'
