Fein FMT 250 - Disassembling Housing Components

FMT 250; FMT 250Q; FMT 250QSL
6. Disassembly
C-SC_CSSM
Version 1.0
2016-11-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 12 of 30
Disassembling housing
1. Unscrew two screws (1).
2. Remove stator (2) from housing.
3. Remove the control rod (3).
Tools:
- Plastic hammer
- Torx T15
2
1
3
