Fein FMT 250 - Disassembling Housing Internals

FMT 250; FMT 250Q; FMT 250QSL
6. Disassembly
C-SC_CSSM
Version 1.0
2016-11-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 13 of 30
Disassembling housing
1. Remove slide switch (1).
2. Remove contact spring (2).
3. Pull connecting cables (3) off stator.
1
2
3
