FMT 250; FMT 250Q; FMT 250QSL
7. Assembly
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
1. Clip slide switch (1) into motor housing.
2. Insert control rod (2) into motor housing.
3. Fit control rod in slide switch.
4. Position contact spring (3).
