FMT 250; FMT 250Q; FMT 250QSL
7. Assembly
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
1. Connect connecting cables (1) to stator as shown in illustration.
2. Insert cables into field coil (2).
3. Insert field coil in motor housing.
Ensure that the ID number (3) of the stator is on the same side as the switch.
