The following items should be checked occasionally for tightness; or if they have
been loosened for maintenance service.
Wheel Nut Torque Specifications
Bolt Size Specification
Front M10x1.25 27.4 ft. lbs. 37 Nm
Rear M10x1.25 27.4 ft. lbs. 37 Nm
NOTE: All nuts that have a cotter pin installed must be serviced by an
authorized Dealer.
Front Wheel Hub Tightening
Front wheel bearing tightness and spindle nut retention are critical component
operations. Service work must be performed by an authorized dealer.
Front Rear
Flange nuts: install with Flange nuts: install with
flat side against wheel flat side against wheel
