Taillight /Brake Light Lamp Replacement
If the taillight/brake light does not work,the lamp may need to be replaced.
1. Remove the lens.
2. Remove lamp and replace it with
recommended lamp.
3. Test the taillight/brake light to see
that it’s working.
4. Reinstall the lens.
Indicator Lamp Replacement
1. Remove mounting panel.
2. Unplug light from harness, depress
locking tabs and remove from pod.
3. Install new light and reassemble panel.
High Beam Headlight Adjustment
The headlight beam can be adjusted up and down.
1. Place the vehicle on a level surface with the headlight approximately 25 ft. (7.6 m)
from a wall.
2. Measure the distance from the floor to the center of the headlight and make a mark
on the wall at the same height.
3. Start the engine and turn the headlight switch to high beam.
4. Observe headlight aim. The most intense part of the headlight beam should be
aimed 2 inches (51 mm) below the mark placed on the wall in step 2.
NOTE: Rider weight must be included on the seat.
5. Loosen pivot bolt and adjust beam to desired position.
6. Tighten nut and bolt.
