Edgebander with glue pot
G 200 / G 220
The machine can be equipped with tracing ball bearings
or with a tracing roller. Both systems can be adjusted
with the screws. Always the same rotations on both
sides.
Never open the screws of the tracing roller system!
!Screw 1
"Screw 2
#Screw 3
$Screw 4
Making adjustments and preparations
8.11.2 Option Flush trimming unit
Fig. 27: Option Flush trimming unit
