User Manual
18 December 2017
8 Display functions
This chapter explains the main functions of the display unit. Next chapter will go more in depth of each menu item.
Turn On the printer/General display unit overview
You can control the printer with the display unit. To navigate through the menu, rotate the button and push the rotary
button to execute a command.
Below is an overview of the main screen of the display unit when the printer is idle and ready for printing.
This menu is active when a print is started:
X: ?.?? mm
Y: ?.?? mm
Z: 0.00 mm
Printer Ready.
E1: 22°C E2: 22°C B: 21°C
After booting up, the printer will show the menu.
The top bar shows the actual temperatures of the
heaters.
Displaying actual positions of the axes. The
question marks will disappear when the axes are
homed.
E1: 20/ 0°C
E2: 20/ 0°C
B: 20/ 0°C
Printer Ready.
E1: 22°C E2: 22°C B: 21°C
Rotating the rotary button to right or left, will display
the 2
nd
main menu. Which displays actual and
setpoint temperature information
Printfile.gcode
41%
Layer x/xx
Status message
E1: 22°C E2: 22°C B: 21°C
