Felt Compulsion Series - Master Parts List

3332
PLEASE NOTE
Felt offers a bearing rebuild kit as well as a complete hardware rebuild kit.
there is also a tool kit for proper removal and installation of the bearings. the
contents of each are displayed in the previous pages. individual parts may also be
ordered. contact your local dealer for more information.
MASTER PARTS LIST
01 Frame Member Front Triangle 1
02 Frame Member Lower Link, Left 1
03 Frame Member Lower Link, Right 1
04 Frame Member Equilink 1
05 Frame Member Upper Link, Left 1
06 Frame Member Upper Link, Right 1
07 Frame Member Chainstay Assembly 1
08 Frame Member Seatstay Assembly 1
09 Pivot Hardware Lower Shock Bolt Custom Cap Screw, M8 x 1.25 x 56.3mm 1
10 Pivot Hardware Shock Bolt Collet Custom Washer, ID 15mm x OD22mm x 3.5mm Thick 1
11 Pivot Hardware Seat Stay Pivot Screw Custom Bolt, M10 x 1.25 x 18.5 2
12 Pivot Hardware Flip Chip (Inside) Custom Oval Nut, M10 x 1.25 2
13 Pivot Hardware Flip Chip (Outside) Custom Oval Washer, ID 10mm 2
14 Pivot Hardware Middle Chip (Inside) Custom Oval Nut, M10 x 1.25 2
15 Pivot Hardware Middle Chip (Outside) Custom Washer, ID 10mm 2
16 Pivot Hardware Lower Pivot Axle Custom Bolt, M15 x 1.25, 72.5mm Long 2
17 Pivot Hardware Upper Pivot Axle Custom Bolt, M15 x 1.25, 78.8mm Long 2
18 Pivot Hardware Collet Cone Custom Washer, ID 15mm x OD22mm x 3.5mm Thick 3
19 Pivot Hardware Main Pivot Spacer Custom Washer, ID 15mm x OD20mm x 2mm Thick 6
20 Pivot Hardware Lower Pivot Bearing Support Custom Washer, ID 15mm x OD17.7mm x 34.7mm Thick 2
21 Pivot Hardware Upper Pivot Bearing Support Custom Spacer, ID 15mm x OD17.7mm x 45mm Thick 1
22 Pivot Hardware Upper Shock Bolt Custom Bolt, M10x1.0, 19.5mm Long 2
23 Pivot Hardware Dropout Pivot Screw Custom Bolt, M12x1.0, 26.5mm Long 2
24 Pivot Hardware Dropout Pivot Spacer Custom Spacer, 12mm ID x 16mm OD x 3mm Thick 4
25 Pivot Hardware Lower Link Pinch Bolt Torx Button Head Cap Screw, M5x0.8x16mm 2
26 Bearing 3802 LLB Max ID 15mm, OD 24mm, 7mm Wide 4
27 Bearing 6802 LLB Max ID 15mm, OD 24mm, 5mm Wide 2
28 Bearing 68012 LLB Max ID 12mm, OD 21mm, 5mm Wide 2
29 Bearing 3801 LLU Max ID 12mm, OD 21mm, 8mm Wide 2
30 Bearing DRF 1017 2RS Max ID 102mm, OD 17mm, 6/7mm Wide 2
31 Bearing JFM1012-12 ID 12mm, OD 12mm, 12mm Wide 4
