Fender 68 Custom Princeton Reverb User Manual

‘68 Custom Princeton
®
Reverb
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: 68 Custom Princeton Reverb
Release Number: PR 722
Part Numbers 68 CUSTOM PRINCETON REVERB 120V 227-2000-000
68 CUSTOM PRINCETON REVERB 110V TW 227-2001-000
68 CUSTOM PRINCETON REVERB 240V AUS 227-2003-000
68 CUSTOM PRINCETON REVERB 230V UK 227-2004-000
68 CUSTOM PRINCETON REVERB 230V ARG 227-2005-000
68 CUSTOM PRINCETON REVERB 230V EUR 227-2006-000
68 CUSTOM PRINCETON REVERB 100V JP 227-2007-000
68 CUSTOM PRINCETON REVERB 220V ROK 227-2009-000
Power Requirement: 125 W
Fuses: F 2A, 250V for 100V versions
F 2A, 250V for 120V versions
F 1.25A, 250V for 230V versions
F 1.25A, 250V for 240V versions
Input Sensitivity:
Input 1 High Level 11 mV – volume at maximum for 12 watts power. Tone controls centered.
Input 2 Low Level 22 mV – volume at maximum for 12 watts power. Tone controls centered.
Power Output: 12W RMS into 8 ohms @ < 10%THD, 1000Hz
Input Impedances >1M Ohms
Speaker Complement: 10” , 8 ohm
Dimensions Height: 16 in (40.6 cm)
Width: 19 7/8 in (50.5 cm)
Depth: 9 1/2 in (24.1 cm)
Weight: 34 lbs (15.7 kg)
Product specifications are subject to change without notice

Fender 68 Custom Princeton Reverb Specifications

General

Amplifier Type	Tube
Output Power	12 Watts
Preamp Tubes	3 x 12AX7
Power Tubes	2 x 6V6
Rectifier	Solid State
Reverb	Yes
Tremolo	Yes
Channels	1
Speaker Size	10"
Controls	Volume, Treble, Bass, Reverb, Speed, Intensity
Model Name	68 Custom Princeton Reverb
Inputs	2
EQ	Treble, Bass
Footswitch I/O	1/4"
Construction Material	Pine
Outputs	1 x 1/4" (Internal Speaker)
Weight	34 lbs (15.4 kg)
Dimensions	16" (40.6 cm) H x 19.875" (50.5 cm) W x 9.5" (24.13 cm) D
Speaker	1x10" Celestion TEN 30
