Fender 68 Custom Princeton Reverb User Manual

‘68 Custom Princeton
®
Reverb
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
6
PARTS LIST: PCB ASSEMBLY
QTY.
PART #
DESCRIPTION
REFERENCE DESIGNATION
1
0027627001
RES FILM 1W 5% 10ohm LL
R60
5
0027353001
RES FILM 1W 5% 100k LL
R5 R28 R36-37 R45
1
0027347001
RES FILM 1W 5% 2.2k LL
R31
1
0037664001
**RES MOX FP 1W 5% 1k LL
R58
2
0075909000
**RES MOX FP 1W 5% 18k LL
R57 R59
2
0033095001
**RES MOX FP 1W 5% 1ohm LL
R20 R32
2
0028021001
**RES MOX 2W 5% 470ohm LL
R39-40
2
0026368001
RES CF 1/2W 5% 100ohm LL
R1 R3
1
0027871001
RES CF 1/2W 5% 1k LL
R27
2
0025116001
RES CF 1/2W 5% 100k LL
R11 R46
6
0053869001
RES CF 1/2W 5% 1M LL
R6 R14-16 R25 R30
6
0026549001
RES CF 1/2W 5% 1.5k LL
R4 R8 R23 R29 R33 R44
4
0025117001
RES CF 1/2W 5% 220k LL
R12 R18-19 R38
1
0041272001
RES CF 1/2W 5% 5.6k LL
R10
1
0037665001
RES CF 1/2W 5% 27k LL
R2
1
0028861001
RES CF 1/2W 5% 3.3k LL
R9
1
0025109001
RES CF 1/2W 5% 47ohm LL
R7
2
0047434001
RES CF 1/2W 5% 56k LL
R17 R26
1
0036955001
RES CF 1/2W 5% 6.8k LL
R52
1
0024981001
RES CF 1/4W 5% 10k LL
R50
1
0025069001
RES CF 1/4W 5% 1M LL
R48
1
0025077001
RES CF 1/4W 5% 3.3M LL
R13
2
0024995001
RES CF 1/4W 5% 68k LL
R47 R51
1
0024986001
RES CF 1/4W 5% 18k LL
R34 (MANUALLY INSTALLED)
1
0028503000
**THERMISTOR 10 ohm 5A C60-11
RT1
1
0037600000
CONTROL SNAPIN 100k B TAPER
R56
1
0037596000
CONTROL SNAPIN 1M 30A TAPER
R53
1
0047540000
CONTROL SNAPIN 250k 15A TAPER
R55
2
0037597000
CONTROL SNAPIN 250k 30A TAPER
R24 R54
1
0037601000
CONTROL SNAPIN 3M 10C TAPER
R21
1
0053860000
**CAP MPF .1uF 250VAC 20%
C17
2
0051406003
CAP CD 220pF 500V 10%
C11 C15 C30-31
1
0020883000
CAP CD 10pF 1000V 10%
C5
1
0020917000
CAP CD 250pF 1000V 10%
C19
1
0020842000
CAP CD 500pF 1000V 10%
C3
1
0037040002
CAP PFF .0033uF 400V 10%
C13
6
0009512001
CAP AE AX 22uF 25V 20%
C1-2 C7-9 C18
4
0024819000
**CAP AE AX 22uF 500V +50%-10%
C26-29
1
0031040000
CAP AE RDL 100uF 100V 20%
C25
2
0024823000
CAP MPF RDL .01uF 400V 10%
C20-21
5
0024833000
CAP MPF RDL .022uF 400V 10%
C4 C6 C12 C14 C23
1
0024854000
CAP MPF RDL .1uF 400V 10%
C24
1
0024855000
CAP MPF RDL .1uF 630V 10%
C22
2
0024835000
CAP MPF RDL .22uF 630V 10%
C10 C16
2
0064089001
DIODE 1N4003
D1 D5
1
0057351001
**DIODE BYD33V
D7
2
0029690001
**DIODE HV 3kV 200mA
D2-3

Fender 68 Custom Princeton Reverb Specifications

General

Amplifier Type	Tube
Output Power	12 Watts
Preamp Tubes	3 x 12AX7
Power Tubes	2 x 6V6
Rectifier	Solid State
Reverb	Yes
Tremolo	Yes
Channels	1
Speaker Size	10"
Controls	Volume, Treble, Bass, Reverb, Speed, Intensity
Model Name	68 Custom Princeton Reverb
Inputs	2
EQ	Treble, Bass
Footswitch I/O	1/4"
Construction Material	Pine
Outputs	1 x 1/4" (Internal Speaker)
Weight	34 lbs (15.4 kg)
Dimensions	16" (40.6 cm) H x 19.875" (50.5 cm) W x 9.5" (24.13 cm) D
Speaker	1x10" Celestion TEN 30
