‘68 Custom Princeton
®
Reverb
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
7
QTY.
PART #
DESCRIPTION
REFERENCE DESIGNATION
1
0047206000
DIODE ZEN 1N5370B 56V 5W 5%
D4
7
0026000001
FSTN TAB MALE .187x.032 PCB MT
P3-6 P12-14
8
0025802000
FSTN TAB MALE .250x.032 PCB MT
P1 P2 P7-11 P17
2
0027408000
HDR .1 CTR 2 CKT SQ PIN
P19A/B
6
0027413000
HDR .1 CTR 6 CKT SQ PIN
P15A/B, P16A/B, P17A/B
2
0059889000
JACK STEREO R/A w/METAL BUSH
J1-2
2
0070334001
**FUSE PICO 7 AMP 125V
F2,F3
PARTS LIST: CHASSIS ASSEMBLY
QTY.
PART #
DESCRIPTION
REFERENCE DESIGNATION
1
0098970000
*PANEL FRONT 68 PRNCTN
1
0075165000
**XFMR 65 PRINCETON REVERB 120V
T2
REF
0075166000
**XFMR 65 PRINCETON REVERB 100V
T2
REF
0075167000
**XFMR 65 PRINCETON REVERB 220/240V
T2
1
0036702000
**FUSE HOLDER 3AG FINGER GRIP
@100/120 VAC VERSIONS
1
0048827000
**FUSE QA 1-1/4x1/4 250v 2A
F1, 100/120 VAC VERSIONS
REF
0036703000
**FUSE HOLDER 5MM FINGER GRIP
@230/240 VAC VERSIONS
REF
0048382000
**FUSE QA 20mm X 5mm 250V 1.25A
F1, 230/240 VAC VERSIONS
6
0022004000
NUT KEPS 8-32 ZINC
1
0037099000
**XFMR REVERB VIBROVERB/65 DLX
T3
1
0069362000
**XFMR OUTPUT PRA
T1
3
0990724000
TUBE SCKT 8 PIN
@V5,V6,V7
18
0038900000
SCRW TF 6-32X1/4 PHP ZI
4
0023606000
TUBE SOCKET 9 PIN
@V1-V4
3
0020424000
TUBE RING UNIVERSAL (277H-2)
@V5,V6,V7
2
0037239000
SCRW TF 8-32x3/8 PHP BLX
3
0018022000
BUSHING SNAP 5/16x17/32 BLK
3
5550112391
TUBE 7025/12AX7A ECC83S GT-ECC83-S
V1, V3, v4
1
5550112400
TUBE 12AT7 ECC81S GT-ECC81-S
V2
1
5550113960
TUBE 5AR4 FULLWAVE RECTIFIER
V7
1
5550113539
TUBE 6V6 GTA 6V6S MATCHED DUET MED
V5, V6 - note: Duet (Matched)
4
0990723000
TUBE SHIELD
@V1-V4
6
0016352049
NUT HEX 3/8-32x3/32 TK NI
Sold in 12 pack
REF
0031153049
WSHR FLAT 3/8x.614 NI
Sold in 12 pack
1
0054642000
**CONNECTOR IEC SNAP IN
1
0036570000
**SWITCH TOGGLE DPST W/NUTS
S1, MAIN POWER SWITCH
1
0021956000
JACK PHONE OPEN CIRCUIT 11
J9, EXTERNAL SPEAKER
2
0056930000
JACK PHONO 2 CND PNL MT #3501FP
J3, J4 REVERB IN/OUT
1
0013043000
JACK PHONE STEREO 12B
J5, FOOTSWITCH (P/O CHS WIRESET)
1
0021550000
JACK PHONE TIP SHUNT 12A
J8, SPEAKER
6
0990930000
KNOB BLK W/WHT STAMP 1-10
1
0054798000
JEWEL ASSY LED
1
0055033049
JEWEL PILOT LITE BLUE
1
0032219049
COLLAR-PILOT LIGHT
1
0021741049
HOLDER IDAL LITE ASSY PILOT
1
0021642049
PILOT LIGHT #T47

Fender 68 Custom Princeton Reverb Specifications

General

Amplifier Type	Tube
Output Power	12 Watts
Preamp Tubes	3 x 12AX7
Power Tubes	2 x 6V6
Rectifier	Solid State
Reverb	Yes
Tremolo	Yes
Channels	1
Speaker Size	10"
Controls	Volume, Treble, Bass, Reverb, Speed, Intensity
Model Name	68 Custom Princeton Reverb
Inputs	2
EQ	Treble, Bass
Footswitch I/O	1/4"
Construction Material	Pine
Outputs	1 x 1/4" (Internal Speaker)
Weight	34 lbs (15.4 kg)
Dimensions	16" (40.6 cm) H x 19.875" (50.5 cm) W x 9.5" (24.13 cm) D
Speaker	1x10" Celestion TEN 30
