‘68 Custom Princeton
®
Reverb
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
PARTS LIST: CHASSIS ASSEMBLY
NUT HOLDER PILOT LIGHT 11/16-27
NUT HEX 3/8-32x3/32 TK NI
**DIODE 1400V 1.3A #BYD33V/EBT/R
CONTROL T-POT 10k 20% CHASSISMTG
STANDOFF NYL PCB SNAP 3/8
C11,C12,C30,C31 @ J3, J4, J5
CABLE ASSY RIBBON 6CKT 2-1/2"
CABLE ASSY RIBBON 2CKT 2-1/2"
PARTS LIST: CABINET ASSEMBLY
*68 PRNCTN CABINET GRILLE BAFFLE ASSY
*68 PRNCTN CABINET UPPER BACK ASSY
*68 PRNCTN CABINET LOWER BACK ASSY
TOLEX "BRAVURA BLACK" BRONCO
WSHR FNSH 8-5/8 FLNGD BLX WX
NUT T 10-32x3/4 STR 3 PRNG BLX
SCRW M 10-32x1-1/8 OHP NI
HANDLE CAP 1 HOLE NI(DWG17420)
HANDLE VINYL BLACK MATTE 9.25" RIBBED
HANDLE REINFORCEMENT STEEL
GLIDE CUP PRESS-IN NI PLATED (0.75 DIA)
CLOTH GRILLE BLACK/SILVER/BLUE
PARTS LIST: END ITEM ASSEMBLY
**CORD PWR W/IEC CONN 100V JPN
**CORD PWR W/IEC CONN 230V
**CORD PWR W/IEC CONN 230V ARG
**CORD PWR W/IEC CONN 230V UK
**CORD PWR W/IEC CONN 250V
**CORD PWR W/IEC CONN DOM
COVER 65 PRINCETON REVERB
STRAP CHASSIS 4-1/2" NICKEL
SCRW M 8-32x3-1/4 OHP NI CP
@CHASSIS MTG Sold in 12 pack
CLAMP CABLE NYL SCRW MNT 5/16
