‘68 Custom Princeton
®
Reverb
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST: END ITEM ASSEMBLY
QTY.
PART #
DESCRIPTION
REFERENCE DESIGNATION
1
0056931000
CABLE REVERB 48" RIGHT ANGLE
1
0064063000
REVERB UNIT 4 SPRING 4AB3C1B
1
0031849000
REVERB BAG
1
0028453000
PAD CARDBOARD REVERB #12FN86
1
0023192000
*NAMEPLATE FNDR 65 TWIN
3
0037985049
SCRW SMA 2x3/8 PHP BLX
@ FENDER NAMEPLATE Sold in 12 pack
8
0037215049
WSHR C/SUNK NICKEL #6
@REAR PANELS Sold in 12 pack
8
0037952049
SCRW SMA #6x1 OHP Ni
@REAR PANELS Sold in 12 pack
1
0038566000
CABLE ASSY SPKR RT ANG 13-1/2"
4
0047821000
SCRW M 10-32 3/4 THP STL BLX
1
7700223000
SPEAKER 10" 8 OHM 30W T5814AX96
1
0075329000
**TUBE CAGE 65 PRINCETON REVERB
ALL MODELS
4
0016006000
SCRW M 10-32x1/2 THP NI
TUBE CAGE MOUNTING
PARTS LIST: FOOTSWITCH ASSY
QTY.
PART #
DESCRIPTION
REFERENCE DESIGNATION
1
0994058000
FOOTSWITCH ASSEMBLY VIB/REV
1
0013172000
PLUG PHONE 3 CONDUCTOR 238 RA
2
0024042000
SWITCH SPST PUSH BUTTON
