Fender Bubbler Chorus - Fender Bubbler Chorus Control Layout; User Interface Elements; Input, Output, and Power Connections

6
18
19
1
3
4
16
13
15
12
8 9
1. Bypass Footswitch
2. Right Output Jack
3. Jewel Indicator
4. Left/Mono Output Jack
5. Level
6. Rate 1
7. Rate 1 LED
8. Depth 1
9. Center LED
10. Rate 2
11. Rate 2 LED
12. Depth 2
13. Sensitivity
14. Sensitivity LED
15. Wave Type Switch
16. Input Jack
17. Slow/Fast Footswitch
18. LED Kill Switch
19. DC Power Connector
