CUSTOM VIBROLUX
CABINET ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028566 CABLE ASSY SPKR RT ANG 13-1/2” (SPEAKER CABLE)
2 022491 CLAMP CABLE NYL SCRW MNT 5/16
.652 036797 CLOTH GRILLE TAN/BRN
4 024695 CORNER 2 HOLE W/ TAB NI CSK
4 024653 GLIDE CABINET NICKEL PLATED (NO INSERT)
1 036901 GRILLE BAFFLE ASSY VVERB/VLUX
2 025395 HANDLE CAP 1 HOLE NI
1 037121 HANDLE STRAP BRN (NO INSERT)
4 022483 INSERT GLIDE CUSHION 1.02 DIA (RUBBER ONLY)
1 032524 INSERT HANDLE (SPRING STEEL
2 024828 LEG AMP TILT 16”
1 036795 NAMEPLATE 62 FENDER
2 021998 NUT FLEX LOCK 10-32 W/NYLON IN (TILT BACK LEG MOUNT)
2 021998 NUT FLEX LOCK 10-32 W/ NYLON IN (TILT BACK LEG MOUNT)
10 021972 NUT T 10-32X3/7 STR 3 PRNG BLX (SPEAKER & HANDLE MOUNT)
1 031849 REVERB BAG (BAG ONLY)
4 037210 SCREW SMA 2X3/8 OHP NI (LOGO MOUNT)
8 047821 SCRW M 10-32 ¾ THP STL BLX (SPEAKER MOUNT)
2 022277 SCRW M 10-32X1-1/5 OHP NI (TILT BACK LEG MOUNT)
4 022244 SCRW M 10-32X1-1/8 OHP NI CONE (CHASSIS MOUNT)
4 022236 SCRW M 8-32X3-1/4 OHP NI CONE (CHASSIS MOUNT)
7 029828 SCRW PB 8X3/4 PHP ZI
4 037667 SCRW SM 8X3/4 FHP NI
8 037952 SCRW SMA #6X1 OHP NI (BACK BOARD MOUNT)
2 031344 SCRW SMA 10X3/4 OHP NI (TILT BACK LEGS STOP MOUNT)
4 011678 SCRW SMA 8X1-1/2 OHP BLX
(BAFFLE MOUNT)
8 037543 SCRW SMAB 8X3/7 OHPNI (CORNER MOUNT)
2 036457 SPEAKER 10” 8 OHM 30 WATTS
2 024745 STRAP CHASSIS 4” NICKEL (CHASSIS MOUNT)
1.62 040882 TOLEX CREAM
2 024656 WASHER LEG STOP TN (TILT BACK LEG STOP)
8 037215 WSHR C’SNK #6 NI (BACKBOARD MOUNT)
6 022319 WSHR FLAT 1/4X6/16 NI (TILT BACK LEG MOUNT, 3 PER)
2 022327 WSHR FLAT 8X7/16 NI (REVERB BAG MOUNT)
4 029527 WSHR FNSH 8-5/8 FLNGD BLX WX (BAFFLE MOUNT)
2 022285 WSHR SP LOCK 1/4X.493 ZI (TILT BACK LEG MOUNT)
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048993 MANUAL OWNERS VIBROLUX REVERB
1 047557 SCHEM REDU W/SERV DIA VIBROLUX
