CUSTOM VIBROLUX
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 49142 RES FILM 1W 5% 39K R37
2 036468 RES MOX FP 1W 5% 470OHM R47,48
2 036470 RES MOX FP 1W 5% 10K R60,61
1 048365 RES MOX FP 1W 5% 18K R23
1 028503 THERMISTOR 10 OHM 5A C60-11 TH1
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
7 018022 BUSHING SNAP 5/16X17/32 BLK (@WIRES THROUGH CHASSIS)
1 026116 BUSHING SR .500X.063X7/16 BLK (@ REVERB CABLE)
1 026038 BUSHING SR .625X.062X37/64 BLK (@100V,120V&AUST OWR CABLE)
1 010401 BUSHING SR .625.125X37/64 WHT (@230V & UK PWR CABLE)
1 026541 CABLE ASSY PWR W/.250 TAB 120V (POWER CABLE 120V ONLY)
1 048463 CABLE ASSY PWR .250 TAB 100V (POWER CABLE 100V ONLY)
1 033331 CABLE ASSY PWR 220/240V (POWER CABLE 230V ONLY)
1 038602 CABLE ASSY PWR AUST .250 TAB (PWR CABLE 240V AUSTRALIA)
1 040993 CABLE ASSY PWR 5A UK .250 TAB (P CABLE UK 240V)
1 036486 CHOKE L1
1 036993 CHS 63 VIBROVERB (RAW CHASSIS)
1 049215 CHS ASSY VIBROLUX 120V
2 022491 CLAMP CABLE NYL SCRW MNT 5/16
1 032219 COLLAR-PILOT LIGHT
1 037300 COVER CAPACITOR VIBROVERB
2 029690001 DIODE HV 3KV 200MA LL CR6,7 (@XV7 &XV8)
1 021956 JACK PHONE OPEN CIRCUIT 11 J7 (EXT. SPEAKER)
1 021550 JACK PHONE TIP SHUNT 12A J6 (SPEAKER)
1 025718 JEWEL #20 PILOT LITE
9 041263 KNOB VINTAGE CREAM
7 016352 NUT HEX 3/8-32X3/32 TK NI (@ FRONT/REAR PANEL JACKS)
1 031625 NUT HOLDER PILOT LIGHT 1/16-27
6 022004 NUT KEPS #8-32 ZINC (POWER OUTPUT XFMR MOUNT)
1 047562 PANEL FRONT VIBROLUX
1 048991 PANEL REAR VIBROLUX
1 021642 PILOT LIGHT #T47
1 064063 REVERB UNI 4 SPRING 4AB 3C1B (PAN)
1 032803 SCRW TF 6-32X1/4 PHP BLX (REAR PANEL MOUNT)
26 038900 SCRW TF 6-32X1/4 PHP ZI (@ TUBE SOCKETS, SMALL XFMRS)
15 028937 SCRW TF 6-32X5/8 PHP ZI TAPTYT (PCB MOUNTING)
4 037239 SCRW TF 8-32X3/8 PHP BLX (@ OUTPUT XFMR, CABLE CLAMP)
15 025936 STANDOFF NYLON PCB SNAPIN 3/8” PCB MOUNTING
1 036570 SWITCH TOGGLE DPST W/NUTS S1 (POWER)
1 037039 SWITCH TOGGLE SPST W/NUTS S3 (STANDBY)
1 023531 TUBE 12AT7 V3 (REVERB DRIVE)
5 013341 TUBE 7025/12AX7WA SOVIET MADE
2 020424 TUBE RING UNIVERSAL (277H-2) (@V7 & V8)
6 023598 TUBE SHIELD (@ PREAMP TUBES V1-V6)
2 023580 TUBE SOCKET 8 PIN XV7-8
6 023606 TUBE SOCKET 9 PN XV1-6
2 039214 TUBE VACUUM 5881/6L6WGC V7-8
2 9904300920 WASHER FLAT .482X.703 NI (@ POWER STANDBY SWITCHES)
3 9904300100 WASHER LCK INTL 3/8X.681X.032 (@ REAR PANEL JACKS
1 036968 XFMR OUTPUT VIBROVERB T3
1 036958 XFMR POWER DOMESTIC VIBROVERB T1
1 049180 XFMR PWR EXPT VIBROVERB/VLUX T1 (EXPORT ONLY)
1 037099 XFMR REVERB VIBROVERB T2
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 047558 CAB ASSY CUSTOM VIBROLUX (COMPLETE CABINET)
1 047558002 BACK ASSY LOWER VIBROLUX (LOWER BACKBOARD)
1 047558001 BACK ASSY UPPER VIBROLUX (UPPER BACKBOARD)

Fender Custom Vibrolux Specifications

General

Type	Tube Amplifier
Output Power	40 Watts
Channels	2
Reverb	Yes
Tremolo	Yes
Controls	Volume, Treble, Bass, Reverb, Speed, Intensity
Effects Loop	No
Inputs	4
Weight	46 lbs (20.9 kg)
Dimensions	10.5" (26.7 cm)
Speaker	Two - 10" Jensen® P10R with Alnico Magnets
