Appendices
NOTES:
The Cyber–Champ™ amplifier does not recognize or transmit System
Common messages.
All knob adjustments (even knobs not captured) are transmitted via MIDI
OUT. MIDI program changes and continuous controller changes are also
“echoed” through the MIDI OUT port. Another Cyber–Champ™ amplifier
connected as a receive MIDI device will “mirror” all these changes.
FUNCTION TRANSMITTED RECOGNIZED REMARKS
Basic Default 1 Omni Transmit Channel is fixed at 1.
Channel Changed X X
Default Mode 3 Mode 2
Mode Messages X X
Altered X X
Note Note Number X X
Number True Voice X X
Velocity Note ON X X
Note OFF X X
After Keys X X
Touch Channel X X
Pitch BenderXX
Control Change O O Continuous Controller Number
is fixed at 11.
Program Implemented O O All program changes in Bank #00.
Change True # 0 – 6, 10-16, 20-26, 0 – 6, 10-16, 20-26, Program changes to program 127 (any bank)
30-36, 40-46, 50-56 30-36, 40-46, 50-56 activates/deactivates the Tuner.
System Exclusive O O See Appendix 2, 3, 4
System Song Position X X
Common Song Select X X
Tune Request X X
System Clock X X
Real Time Commands X X
Local On/Off X X
Auxiliary All Notes Off X X
Messages Active Sensing X X
System Reset X X
GM ON X X
Mode 1: Omni On, Poly Mode 2: Omni On, Mono O: Yes
Mode 3: Omni Off, Poly Mode 4: Omni Off, Mono X: No
4
4
✧
✧
Appendices
Appendices
Appendix 1 MIDI Implementation Chart
