Fender Frontman 15B Operating Instructions

TYPE: PR 497
PART NUMBER: (120 V, 60 Hz) US 023-1503-000
(110 V, 60 Hz) TW 023-1513-900
(240 V, 50 Hz) AUS 023-1533-900
(230 V, 50 Hz) UK 023-1543-900
(220 V, 50 Hz) ARG 023-1553-900
(230 V, 50 Hz) EUR 023-1563-900
(100 V, 50 Hz) JPN 023-1573-900
(220 V, 60 Hz) ROK 023-1593-900
POWER REQUIREMENTS: 38 W
POWER OUTPUT: 15 W R.M.S. at 5 % THD
RATED LOAD IMPEDANCE: 8 Ω
COMPRESSION RANGE: 15 dB
INPUT IMPEDANCE: 202 k Ω
FULL POWER SENSITIVITY INSTRUMENT: 10 mV at onset of compression
(1 kHz) AUX IN: 800 mV at onset of compression
EQUALIZATION RANGE LOW: ±15 dB at 40 Hz
MID: ±15 dB at 800 Hz
HIGH: ±15 dB at 8 kHz
SPEAKER COMPLEMENT: One 8Ω Special Design 8" speaker
DIMENSIONS HEIGHT: 15 in (38.1 cm)
WIDTH: 17.25 in (34.3 cm)
DEPTH: 9.75 in (24.8 cm)
WEIGHT: 21 lb (9.5 kg)
Product specifications are subject to change without notice.
7
wwwwww .. ffeennddeerr.. ccoomm ✧ wwwwww ..mmrrggeeaarrhheeaadd.. nneett
Specifications
Specifications

Fender Frontman 15B Specifications

Power

power requirement (100V version)	100V AC, 50/60 Hz, 45W
power requirement (120V version)	120V AC, 60 Hz, 45W
power requirement (230V version)	230V AC, 50 Hz, 45W
power requirement (240V version)	230V AC, 50 Hz, 45W
power output	15W R.M.S.

Speaker and Impedance

rated load impedance	8Ω
speaker complement	One 8Ω Special Design, 8" Speaker (P/N 025421)
input impedance	202k Ω

Dimensions and Weight

height	15 in. 38.1 cm
width	17.25 in. 34.3 cm
depth	9.75 in. 24.8 cm
weight	21 lbs. 9.5 kg
