ROC PRO 700
SPECIFICATIONS
Product Release No.: PR 242 (This is not a model number)
Input impedance: > 1MΩ
Nominal level: 100mV
Power output: 65 Watts RMS into 8 Ω @ 5% THD
Effects loop Nominal level; Selectable +4, -7, -16 dBV
Output Impedance: 1.2kΩ
Input Impedance: 100kΩ
Dimensions: Height:16.5" (41.9 cm)
Width: 20.5" (52.0 cm)
Depth: 9.75" (24.7 cm)
Weight: 30 lbs. (13.6 kg)
Product specifications are subject to change without notice
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 041481001 PCB ASSY PERFORMER 650 ALL V’S (STUFFED)
1 028104 BUTTON PUSH SWITCH BLACK (@S2)
1 028577 CABLE ASSY REVERB 30” (@P1-4)
2 029719 CABLE FLAT 5CKT 10” (@P5,6)
4 038689 CAP AE AX .47uF 100V 20% C16,17,33,37
4 026517 CAP AE AX 2.2uF 50V 20% C9,41,42,44
1 038691 CAP AE AX 4.7uF 50V 20% C43
1 038692 CAP AE AX 10uF 50V 20% C61
7 025960 CAP AE AX 22uF 16V 20% C4,10,32,34,47,48,60
2 028471 CAP AE RDL 47uF 50V 20% C45,46
2 028492 CAP AE RDL 1000uF 16V 20% C53,54
2 028042 CAP AE RDL 2200uF 50V C51.52
1 038873 CAP CA 22PF 100V 5% C40
1 039256 CAP CA 68PF 100V 5% C31
3 038699 CAP CA 100PF 100V 5% C8,18,36
1 039260 CAP CA 270PF 100V 5% C7
3 038701 CAP CA 470PF 50V 5% C15,26,28
1 038874 CAP CA 560PF 50V 5% C22
