Fender ROC PRO 700 - Chassis Assembly

ROC PRO 700
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 024985 RES CF 1/4W 5% 15K R3,5
6 024987 RES CF 1/4W 5% 22K R9,14,23,24,40,49
2 024988 RES CF 1/4W 5% 27K R84,86
7 024993 RES CF 1/4W 5% 47K R27,43,45,51,80,81,82
1 028990 RES CF 1/4W 5% 51K R66
1 026507 RES CF 1/4W 5% 62K R50
2 029613 RES CF 1/4W 5% 91K
R20,21
5 024997 RES CF 1/4W 5% 100K R31,57,64,69,128
2 025058 RES CF 1/4W 5% 180K R15,30
4 025059 RES CF 1/4W 5% 220K R16,55,73,78
3 025065 RES CF 1/4W 5% 470K R56,79,130
2 028018 RES CF 1/4W 5% 510K R4,7
2 025067 RES CF 1/4W 5% 680K R85,132
1 029617 RES CF 1/4W 5% 750K R1
14 025069 RES CF 1/4W 5% 1M
R2,39,76,77,113,116-119,123,124,131,134,135
1 025084 RES CF 1/4W 5% 10M R129
3 031767
RES CF 1/2W 5% 15Ω
R62,103,104
1 026493 RES CF 1/2W 5% 2.7K R126
1 026549 RES CF 1/2W 5% 1.5K R109
1 028045
RES FILM 1W 5% 220Ω
R87
2 028030
RES FILM 1W 5% 680Ω
R88,89
1 029722 RES FILM 1W 5% 1K R110
3 027346 FES FILM 1W 5% 1.2K R100,101,102
2 028029 RES FILM 1W 5% 1.5K R90,91
2 037354 RES CF 1W 5% 4.7K R92,93
1 027478
RES WW BT 5W 10% .22Ω
R98
2 028028
RES WW BT 5W 10% .47Ω
R96,97
7 041256
RES WW 5W 10% 470Ω
R32-34, 105-108
2 027638 SCRW TF 4-40X3/8 HWHS ZI (Q5,6)
2 032908 SCRW TF 6-32X3/8 PHP ZI (HEATSINK TO PCB MOUNT)
1 029167 SOCKET TUBE 9 PIN PCB MOUNT XV1
1 028091 SWITCH PUSH SLFLK SHORT STROKE DPDT S2 (CHANNEL SELECT)
1 038652 SWITCH SLIDE 4P3T S1 (LEVEL)
1 028503
THERMISTOR 10Ω 5AMP C60-11
TH1
1 013341 TUBE VACUUM 7025-12AX7 V1
2 028169 WSHR SHLDR NYL 5/32X1/4 (@Q5,6)
1 041465 XSTR N-CHNL J-FET J113 TO-92 Q3
3 014689 XSTR N-CHNL J-FET J111 TO-92 Q1,2,4
1 016739 XSTR NPN 2N4401 TO-92 Q7
1 028114 XSTR NPN TIP142 TO-218AC Q5
1 028115 XSTR PNP TIP147 TO-218AC Q6
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050318 CHS ASSY ROC PRO 700 120V (COMPLETE CHASSIS)
1 021709 BUSHING SR .437X.602X13/32 BLK (@ SPEAKER CABLE)
1 026038 BUSHING SR .625X.062X37/64 BLK (@ POWER CABLE 100V/120V)
1 010401 BUSHING SR .625X.125X37/64 WHT 230V (@ POWER CABLE 230V)
1 026116 BUSHING SR .500X.063X7/16 BLK (@ REVERB CABLE)
1 026527 CABLE ASSY POWER W/.187 TABS (100V/120 ONLY)
1 026528 CABLE ASSY POWER 230V W/.187 TABS (POWER CABLE 230V EXPORT)
1 036479 CABLE ASSY POWER AUST. W/.187 TABS (240V AUSTRALIA ONLY)
1 028560 END BELL XFMR 85W
1 028499 HEATSINK BAR (COUPLER TO CHASSIS)
10 019798 KNOB ROTARY SS
4 028591 NUT ACORN 8-32 (TRANSFORMER MOUNT)
1 050315 PANEL FRONT ROC PRO 700
1 050316 PANEL REAR ROC PRO 700
3 028500 SCRW TF 8-32X3/4 HWH SLTD ZI (CHASSIS TO HEATSINK MOUNT)
4 028937 SCRW TF 6—32X5/8 PHPZI ROLOK (PCB TO CHASSIS MOUNT)
