Fender ROC PRO 700 - Cabinet Assembly; Footswitch Assembly; Miscellaneous

ROC PRO 700
CHASSIS ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 025935 SWITCH POWER DPST 120V DOMESTIC ONLY
1 039287 SWITCH POWER DPST .187 TAB GLOBAL (EXPORT ONLY)
REF 016420 TUBING SHRINK 1-1/2 BLK (VACUUM TUBE MOUNT)
4 030007 WSHR LCK INTL 8X.330X.02 ZI (TRANSFORMER MOUNT)
1 027668 XFMR PWR 120V 85A (120 DOMESTIC ONLY)
1 039357 XFMR PWR EXP 230V (100V/230V EXPORT ONLY)
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050254 CAB ASSY ROC PRO 700/DLX 112+ (COMPLETE CABINET)
1 022491 CLAMP CABLE NYL SCRW MNT 5/16 (@REVERB CABLE)
4 026566 CORNER 2 HOLE W/ TAB NI
2 026568 CORNER 3 HOLE NI
4 029821 EYELET RFLNGD .215 OD X.315L (@REVERB PAN)
4 019276 GLIDE CAB 1.24X.335NI (STEEL ONLY, NO INSERT)
4 019275 GLIDE CUSHION INSERT (RUBBER ONLY)
1 050335 GRILLE ROC PRO 700 (COMPLETE GRILLE)
1 027846 HANDLE 9.25” NO LOGO (RUBBER ONLY, NO INSERT)
2 019279 HANDLE CAP 2-3/16 NI (HANDLE MOUNT)
1 032524 INSERT HANDLE (SPRING STEEL)
1 047600 NAMEPLATE LOGO BLACK
4 050311 NUT 2-56 NYLON INSERT 2CNME-2 (LOGO MOUNT)
8 021972 NUT T 10-32X3/4 STR 3 PRNG BLX (HANDLE/SPEAKER MOUNT)
1 028055
REVERB UNIT 800 Ω 8EB2C1B DN
10 026571 SCRW CORNER MOUNTING
4 022244 SCRW M 10-32X1-1/8 OHP NI (HANDLE MOUNT)
4 026577 SCRW M 10-32X1 PHP BLX (SPEAKER MOUNT)
6 036199 SCRW M 8-32X1-3/16 OHP BLX WX (CHASSIS MOUNT)
5 029828 SCRW PB 8X3/4 PHP ZI (REVERB PAN MOUNT)
8 011678 SCRW SMA 8X1-1/2 OPH BLX (GRILLE MOUNT)
4 050312 SCRW M 2-56X3/8 FHP NI (LOGO MOUNT)
4 026652 SCRW WOOD 8X1 FH (GLIDE MOUNT)
8 050317 STANDOFF RUBBER .75 DIA X.77 (GRILLE MOUNT)
1 025923
SPEAKER 12” 8 Ω 75 WATT
12 029527 WSHR FNSH 8-5/8 FLNGD BLX WX (CHASSIS/GRILLE MOUNT)
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028122 FTSW ASSY 2 BTTN REVERB F/LOGO (COMPLETE FOOTSWITCH)
1 028895 CABLE ASSY FTSW RT ANG 12’
2 006260 DIODE 1N4448 SIGNAL BENT CR1,2
1 037036 JACK PHONE PCB MONO CA PREMIUM J1
2 028039 LED RED 5X5XMM SLB-55VR3 LD1,2
1 028448 PCB ASSY FTSW 2 BUTTON
8 028889 SCRW SMB 6X1/4 PHP (END CAP MOUNT)
2 03492 1SPACER RND NYL .147X.250X.780
2 028714 SWITCH PUSH SPDT
2 031899 WSHR NYL .485X.775X.150 TK
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050367 MANUAL OWNERS ROC PRO 700
1 050377 SCHEM REDU W/SVC ROC PRO 700
