Fender Rumble 60 - Specifications; General and Power Specifications; Impedance and Sensitivity; Equalization, Effects Loop, and Speaker

Specifications
Specifications
7
wwwwww .. ffeennddeerr.. ccoomm ✧ wwwwww ..mmrrggeeaarrhheeaadd.. nneett
TYPE: PR 504
PART NUMBER: 2315500910 (120 V, 60 Hz) US
023-1515-900 (110 V, 60 Hz) TW
023-1535-900 (240 V, 50 Hz) AUS
023-1545-900 (230 V, 50 Hz) UK
023-1555-900 (220 V, 50 Hz) ARG
023-1565-900 (230 V, 50 Hz) EUR
023-1575-900 (100 V, 50 Hz) JPN
023-1595-900 (220 V, 60 Hz) ROK
POWER REQUIREMENTS: 180 W
POWER OUTPUT (@ 1kHz): 60 W R.M.S. at <3% THD
50 W R.M.S. at <.02% THD at onset of limiter
RATED LOAD IMPEDANCE: 8 Ω
INPUT IMPEDANCE INPUT 1: 718 k Ω
INPUT 2: 128 k Ω
CD IN: 100 k Ω
FULL POWER SENSITIVITY INPUT 1: 50 mV
INPUT 2: 100 mV
POWER AMP IN: 750 mV
CD IN: 1.1 V
EQUALIZATION RANGE BASS: ±15 dB at 50 Hz
LOW MID: ±15 dB at 330 Hz
HIGH MID: ±15 dB at 1.6 kHz
TREBLE: ±15 dB at 8 kHz
EFFECTS LOOP SEND IMPEDANCE: 1 k Ω
RETURN IMPEDANCE: 18 k Ω
SPEAKER COMPLEMENT: One 8 Ω Special Design 12" speaker
DIMENSIONS HEIGHT: 22.5 in (57.4 cm)
WIDTH: 18.75 in (47.8 cm)
DEPTH: 12.25 in (31.2 cm)
WEIGHT: 46 lb (20.7 kg)
Product specifications are subject to change without notice.
(VOLUME knob @ 10,
EQ knobs @ 0 and MID-
SCOOP button OUT)
2315500910
2315501910
2315503910
2315504910
2315505910
2315506910
2315507910
2315509910
