STAGE® 100/160 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
10
PARTS LIST:
CHASSIS ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0028564000 END BELL XFMR 185 Series @ XFMR
4 0028591000 NUT ACORN 8-32 @ XFMR
4 0030007000 WSHR LCK INTL 8x.330x.02 ZI @ XFMR
PARTS LIST:
CABINET ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
4 0026566000 CORNER 2 HOLE w/TAB NI
2 0026568000 CORNER 3 HOLE NI
10 0026571000 SCRW SMAB 8X5/8 THP NI @ CORNERS, STAGE 100/160 DSP
14 0026571000 SCRW SMAB 8X5/8 THP NI @ CORNERS/FOOT, STAGE 100H DSP
4 0019276000 GLIDE CAB 1.24x.335 NI STAGE 100/160 DSP
4 0019275000 INSERT GLIDE CUSHION 1.27 DIA @ GLIDE, STAGE 100/160 DSP
4 0026625000 SCRW WOOD 8x1 FH @ GLIDE, STAGE 100/160 DSP
4 0029323000 FOOT RUBBER 1.0 DIA SMALL STAGE 100H DSP
1 0027846000 HANDLE 9.25" NO LOGO
2 0019279000 HANDLE CAP 2 HOLE NICKEL @ HANDLE
1 0032524000 INSERT HANDLE @ HANDLE
4 0022244000 SCRW M 10-32x1-1/8 OHP NI @ HANDLE
4 0056482000 MOUNTING PLATE EL COM @ CASTERS, STAGE 160 DSP
16 0027199000 SCRW SMAB 10x3/4 PHP NI @ MOUNTING PLATE, STAGE 160 DSP
8 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX @ HANDLE/SPEAKER, STAGE 100 DSP
12 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX @ HANDLE/SPEAKERS, STAGE 160 DSP
4 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX @ HANDLE, STAGE 100H DSP
0.02 0027648000 TAPE ALUM 6"x60YDS
0.33 0031752000 RIBBON PULL-TAB @ GRILLE, STAGE 100H DSP
1.06 0026570000 TOLEX "BRAVURA BLACK" STAGE 100 DSP
1.18 0026570000 TOLEX "BRAVURA BLACK" STAGE 160 DSP
1.01 0026570000 TOLEX "BRAVURA BLACK" STAGE 100H DSP
0.39 0029085000 VELCRO STRIP LOOP 1.5"wd BLK @ FTSW LOOPS
0.39 0029086000 VELCRO STRIP HOOK 1.5"wd BLK @ FTSW LOOPS
0.17 0029085000 VELCRO STRIP LOOP 1.5"wd BLK @ GRILLE, STAGE 160 DSP
0.25 0029085000 VELCRO STRIP LOOP 1.5"wd BLK @ GRILLE, STAGE 160 DSP
0.22 0029085000 VELCRO STRIP LOOP 1.5"wd BLK @ GRILLE, STAGE 100H DSP
0.17 0029086000 VELCRO STRIP HOOK 1.5"wd BLK @ BAFFLE, STAGE 100 DSP
0.25 0029086000 VELCRO STRIP HOOK 1.5"wd BLK @ BAFFLE, STAGE 160 DSP
0.22 0029086000 VELCRO STRIP HOOK 1.5"wd BLK @ BAFFLE, STAGE 100H DSP
PARTS LIST:
END ITEM ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0040025000 CAB ASSY STG112/100/RP1000MKII STAGE 100 DSP
- 0040071000 CAB ASSY ULT CHORUS/STAGE160 STAGE 160 DSP
- 0040988000 CAB ASSY STAGE100H STAGE 100H DSP
1 0038566000 CABLE ASSY SPKR RT ANG 13-1/2" STAGE 100 DSP
2 0038566000 CABLE ASSY SPKR RT ANG 13-1/2" STAGE 160 DSP
4 0056483000 CASTER SWIVEL EL COM 2-12CABS STAGE 160 DSP
1 0047248000
**CORD PWR W/IEC CONN DOM
120V DOMESTIC
- 0047249000
**CORD PWR W/IEC CONN 230V UK
230V UK
- 0047250000
**CORD PWR W/IEC CONN 240V
240V AUST
- 0047251000
**CORD PWR W/IEC CONN 230V
230V EUR
- 0057674000
**CORD PWR W/IEC 230V ARG
230V ARG
- 0053997000
**CORD PWR W/IEC CONN 100V JPN
100V JPN
1 0057601000 FTSW ASSY 4 BTN STAGE DSP CH SEL-DRV/MRDRV-EFX-REV
To Next Page
