STAGE® 100/160 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST: uDSP – PCB ASSEMBLY (continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
4
*
RES 0805 MF 1/10W 5% 1k
1
*
RES 0805 MF 1/10W 5% 2k
1
*
RES 0805 MF 1/10W 5% 3.3k
2
*
RES 0805 MF 1/10W 5% 4.7k
1
*
RES 0805 MF 1/10W 5% 15k
1
*
RES 0805 MF 1/10W 5% 47k
1
*
IC SMT SOCKET PLCC 44-TT
1
*
IC SMT TLC549 AD
1
*
IC SMT SRAM 64Kx16
1
*
IC SMT COUNTER 74LV4040
1
*
IC SMT HEX SCHMITT-T INV 74HC14
1
*
IC SMT VREG +3.3V LM1117
1
*
IC SMT CODEC TLC320AD77C
1
*
IC SMT DSP TMS320VC5402PGE
1
*
IC SMT VREG +1.8V 150mA TPS76318
1
*
IC SMT RESET 5V MC34064D-5
1
*
XTAL 20MHz HC49SD
PARTS LIST: CHASSIS ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0057359000 CABLE RIBBON 16 CKT W/2 CONN CONNECT uDSP ASSY TO MAIN PCB
1
*
CHASSIS STAGE 100 DSP STAGE 100 DSP
-
*
CHASSIS STAGE 160 DSP STAGE 160 DSP
1 0054642000 CONNECTOR IEC SNAP IN
1 0053884000
**FUSE QA 20mmX5mm 125V 4A UL/CSA
100-120V ONLY
- 0020795000
**FUSE QA 20mmx5mm 250v 2.5A
220-240V ONLY
1 0039203000 HEATSINK BAR STAGE 112SE @ HEATSINK
7 0028500000 SCRW TF 8-32x3/4 HWH SLTD Z1 @ HEATSINK
1 0054798000 JEWEL ASSY LED
1 0031625000 NUT HOLDER PILOT LIGHT 11/16-27 @ JEWEL ASSY
12 0053986000 KNOB ROTARY SS W/CHR INSERT @ CONTROLS
2 0057256000 KNOB ROTARY ARROW W/CHRM INSRT @ ENCODERS
1
*
LABEL GROUNDING SEMKO @ GND
1 0038900000 SCRW TF 6-32X1/4 PHP ZI @ GND
-
*
LABEL VOLTAGE 230V @ REAR PANEL
-
*
LABEL VOLTAGE 240V @ REAR PANEL
-
*
LABEL VOLTAGE 100V @ REAR PANEL
1 0057613000 PANEL FRONT STAGE 100 DSP STAGE 100 DSP
- 0057635000 PANEL FRONT STAGE 160 DSP STAGE 160 DSP
1
*
PANEL REAR STAGE 100 DSP STAGE 100 DSP
-
*
PANEL REAR STAGE 160 DSP STAGE 160 DSP
6 0053479000 NUT HEX 7/16 20X1/8 NI @ JACKS
6 0053480000 WASHER FLAT .442 X.692 NI @ JACKS
2 0051155000 SCRW SMB #4X3/8 PHP BLX @ XLR JACK
4 0051404000 STANDOFF NYLON BLK .375 @ uDSP ASSY
1 0025936000 STANDOFF NYL PCB SNAP 3/8" NAT @ MAIN PCB
1 0028937000 SCRW TF 6-32x5/8 PHP ZI TAPTYT @ STANDOFF
1 0039236000
**SWITCH ROCKER DPST PSEUDO-IEC
100-120V ONLY
- 0040582000
**SWITCH DPST .250 TAB GLOBAL
220-240V ONLY
1 0054258000
**WIRE SET CHS STAGE 100/160 DOM
120V ONLY
- 0054262000
**WIRE SET CHS STAGE 100/160 EXP
100V, 220-240V ONLY
1 0039129000
**XFMR PWR STAGE 120V
120V ONLY
- 0039084000
**XFMR PWR STAGE 112SE EXP
100V, 220-240V ONLY
