SUPER CHAMP
®
XD
(This is the model name for warranty claims)
10
1 0036702000 **FUSE CARRIER
1 0054642000 **IEC CONNECTOR
1 0054798000 POWER JEWEL RED
1 0055812000 TULIP LED ASSY
1 0022913000 **XFMR OUTPUT 2-6V6GT to 8 Ohms T2
1 0039287000 **SWITCH POWER
1 0074592000 **XFMR PWR CHAMP XD AMPS 120V T1
1 0074595000 **XFMR PWR CHAMP XD AMPS 100V T1
1 0074596000 **XFMR PWR CHAMP XD AMPS 230V T1
1 0074597000 **XFMR PWR CHAMP XD AMPS 240V T1
1 0077982000 **FUSE 1 ¼ X ¼ 3A FAST ACTING F2 (100/120V UNITS)
1 0020793000 **FUSE 5mmX20MM 1.6A FAST ACTING F2(230/240V UNITS)
2 0057347000 KNOB ROTARY W/CHROME INSERT FX SELECT/VOICE
5 0054419000 KNOB ROTARY W/CHROME INSERT VOLUME/TONE
1 0073858000 SPEAKER 10” SUPER CHAMP XD
1 0074594000 *PCB ASSY uDSP SUPER CHAMP XD
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
