SUPER CHAMP
®
XD
(This is the model name for warranty claims)
9
.PARTS LIST: MAIN PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0029607001 RES CF 1/4W 5% 620ohm LL R57
1 0024995001 RES CF 1/4W 5% 68k LL R30
1 0029608001 RES CF 1/4W 5% 750ohm LL R55
1 0024996001 RES CF 1/4W 5% 82k LL R28
2 0029597001 RES CF 1/4W 5% 91ohm LL R58 R68
1 0027353001 RES FILM 1W 5% 100k LL R21
1 0016540001 RES MF 1/4W 1% 2.61k LL R69
2 0016946001 RES MF 1/4W 1% 825ohm LL R70 R78
2 0036351001 RES MOX 2W 5% 100ohm LL R87-88
1 0041268001 RES MOX 2W 5% 10k LL R47
1 0036921001 RES MOX 2W 5% 1k LL R79
2 0028021001 RES MOX 2W 5% 470ohm LL R4 R25
1 0033095001 RES MOX FP 1W 5% 1ohm LL R20
1 0028091000 SWITCH PUSH SLFLK SHORT STROKE S1
1 0994020002 DUET (MATCHED) 6V6GTA /STR391A V2-3
1 0994024000 TUBE 7025/12AX7WA (RUSSIAN) V1
7 REF WIRE JUMPER
WJ8 WJ1A WJ1B WJ2A WJ2B WJ3A WJ3B
1 REF WIRE JUMPER WJ6
1 0014689003 XSTR N-CH JFET J111 TO-92 Q3
2 0016739003 XSTR NPN 2N4401 TO-92 Q4-5
2 0016742003 XSTR PNP 2N4403 TO-92 Q1-2
PARTS LIST: MISCELLANOUS
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
