Fender THE TRAPPER - Page 2

14
15
1
3
11
9
6
1. Bypass Footswitch
2. Jewel Indicator
3. Output Jack
4. Contour
5. Tone
6. Level 1
7. Level 1 LED
8. Level 2
9. Fuzz 2
10. Octave Switch
11. Input Jack
12. Select Footswitch
13. Low Battery Indicator
14. LED Kill Switch
15. DC Power Connector
4
12
LEDs
9V DC
INPUT
THE TRAPPER
OCTAVE
CONTOUR
LEVEL 1
FUZZ 2
13
2
10
SELECTBYPASS
7 85
LEVEL 2TONE
