Fender TRE-VERB - Overview

6
18
20
1
4
15
13
12
987 11
1. Tremolo Footswitch
2. Tremolo LED Indicator
3. Right Output Jack
4. Left/Mono Output Jack
5. Rate
6. Level
7. Rate LED
8. Depth
9. Tremolo Type Switch
10. Reverb Type Switch
11. Blend
12. Tone
13. Dwell
14. Right Input Jack
15. Left/Mono Input Jack
16. Reverb LED Indicator
17. Reverb Footswitch
18. LED Kill Switch
19. Path Switch
20. DC Power Connector
19
5
17
2 16
3
14
LEDs
9V DC
INPUT
PATH
TRE-VERB
RATE DEPTH DWELL
LEVEL TONE
TREMOLO REVERB
BLEND
’63
’65
PLATE
OPTO
BIAS
HM
10
