ULTIMATE CHORUS
CHASSIS ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 038602 CABLE ASSY PWR AUST W/.250 TAB (240V AUSTRALIA ONLY)
1 033045 END BELL XFMR (PWR CHOR) (TRANSFORMER MOUNT)
1 031726 HEATSINK BAR (M-80) (COUPLER TO CHASSIS)
14 026402 KNOB POINTER BLAKC
4 028591 NUT ACORN 8-32 (TRANSFORMER MOUNT)
1 049104 PANEL FRONT LEXAN ULTIMATE CHROUS
1 049105 PANEL REAR VINYL ULTIMATE CHORUS
5 028500 SCREW TF 8-32X3/4 SLTD HWH ZI (HEATSINK TO CHASSIS)
4 028937 SCREW TF 6-32X5/8 ROLOK PHP ZI (PCB TO CHASSIS MOUNT)
1 038900 SCREW TF 6-32X1/4 [J[ ZO (@ GROUND LUG)
1 039236 SWITCH PWR ROCKER DPST PSEUDO-IEC
.870”X1.181” HOLE
(100/120V)
1 040582 SWITCH PWR ROCKER DPST IEC
.870”X1.181” HOLE
230V EXPORT
4 030007 WASHER LOCK INTL 8X.330X.02 ZI (TRANSFORMER MOUNT)
1 031668 XFORMER PWR 120V 125 WATT (120V DOMESTIC)
1 039253 XFORMER PWR 100/230V 125 WATT (100V/115V/230V EXPORT)
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040071 CABINET ASSY ULTRA CHORUS/PRO 185 (COMPLETE CABINET)
4 023505 CASTER MOUNTING PLATE
4 023513 CASTER SWIVEL STEEL
4 026566 CORNER 2 HOLE W/ TAB NI (BOTTOM FRONT, TOP REAR)
2 026568 CORNER 3 HOLE NI (BOTTOM REAR)
4 029821 EYELET RFLNGD .215 OD X.315 L BRASS (REVERB PAN MOUNT)
4 019275 GLIDE CUSHION INSERT (RUBBER ONLY)
4 019276 GLIDE CABINET 1.24X.335 NI (STEEL ONLY)
1 040072 GRILLE ASSY “ULTRA CHORUS” (COMPLETE GRILLE)
1 011298 NAMEPLATE FENDER SMALL (LOGO)
12 021972 NUT T 10-32X3/4 STR 3 PRNG BLX (SPEAKER, HANDLE MOUNT)
1 028055 REVERB UNIT 800 OHM 8EB2C1B DN (PAN)
4 022244 SCREW M 10-32X1-1/8 OHP NI (HANDLE MOUNTING)
10 026571 SCREW CORNER MOUNTING
4 026625 SCREW WOOD 8X1” FH (GLIDE MOUNTING)
16 027199 SCREW SMAB 10X3/4 PHP NI (CASTER PLATE MOUNT)
2 018113 SCREW SMA #4X1/2” OHP BLX (NAMEPLATE MOUNTING)
8 026577 SCREW M 10-32X1” PHP BLX (SPEAKER MOUNTING)
5 029828 SCREW PB 8X3/4 PHP ZI (REVERB PAN/CBL CLMP MT)
6 036199 SCREW M 8-32X1-3/16 OHP BLX WX (CHASSIS MOUNT)
2 025923 SPEAKER 12” 8 OHM 75 WATT
6 029527 WASHER FNSH 8-5/8 FLNDG BLX WX (CHASSIS MOUNT)
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 029972 FOOTSWITCH 2 BTTN CHAN/CHORUS (COMPLETE FOOTSWITCH)
1 028895 CABLE ASSY FOOTSWITCH RT ANGLE 12” (FOOTSWITCH CABLE)
2 006260 DIODE 1N4448 SIGNAL BENT 75PRV CR1,2
1 037036 JACK PHONE PCB MONO CA PREMIUM J1
2 028039 LED 5x5mm RED SLB-55VR3 LD1,2
1 028448 PCB ASSY FTSW 2 BUTTON (STUFFED)
2 034921 SPACER .147X.250X.780 RND NYLON (LED SPACERS)
8 028889 SCREW SMB #6X1/4” PHP (END PANEL MOUNT)
2 028714 SWITCH PUSH SPDT S1,2
2 031899 WASHER NYL .485X.775X.150 TK (SWITCH SPACER)
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 049106 MANUAL OWNERS ULTIMATE CHORUS
1 039243 SCHEM W/SERVICE DA. “ULTRA CHORUS”
(USE FOR “ULTRA CHORUS” AND “ULTIMATE
CHORUS”
To Next Page
