Fenix HL10 - Headlamp Operation and Functionality; Operation Instruction; Spotlight Floodlight Selection; Intelligent Memory Circuit

◎ As a headlamp, 180-degree tilt mechanism adjusts the beam when needed
◎ As a flashlight, supports tail standing, works as a candle
◎ Digitally regulated output maintains constant brightness
◎ Reverse polarity protection, to protect from improper battery installation
◎ Made of durable aircraft-grade aluminum
Operation Instruction
ON/OFF
Press and hold the switch for 0.5 seconds to turn ON/OFF the lamp.
Output Selection
With the lamp on, click the switch to cycle through Low→Mid→High.
Spotlight/Floodlight Selection
1. Take out the lamp from the holder.
2. Rotate the optical lens between the spot mark and flood mark on the lower edge.
Intelligent Memory Circuit
The lamp remembers the last used brightness level, the next time it is turned on, it will recall
that previously used brightness level.
Battery Specifications
Type
Dimensions
Nominal Voltage
Usability
Ni-MH Battery
AAA
1.2V
Recommended
√√
Alkaline Battery
AAA
1.5V
Usable
√
Rechargeable Battery
(Li-ion)
10440/10450
3.7V
Banned
×
Warning:
1. Fenix recommends using excellent quality battery. If the headlamp will not be used for an
extended period, remove the battery, or the headlamp could be damaged by electrolyte
leakage or battery explosion.
