Cleaning
- First read the safety instructions for cleaning on page 5 of this manual.
- Open the clamping levers (5) and disconnect the air couplings of the main hopper(4). Slide
the main hopper(4) backwards to take it out. The main hopper (4) can now be cleaned.
CAUTION: use safety goggles when cleaning the hopper with compressed air.
- Reinstall the main hopper(4) and close the clamping levers (5). Then reconnect the air
couplings.
- Open the door(3). Disconnect the large white connector off the motor cable. Then pull the
dosing part (6) backwards. The dosing part (6) can now be cleaned. CAUTION: use safety
goggles when cleaning the hopper with compressed air.
- Place the dosing part(3) back into the housing (2). Reconnect the motor cable to the
connector. Close the door(3).
