PLANER
THE NUMBERS IN THE FOLLOWING TEXT
CORRESPOND WITH THE PICTURES AT PAGE 2.
TECHNICAL DATA
PRODUCT DESCRIPTION
BRIEF DESCRIPTION
This doubly insulated electric tool is designed to be
manually operated. It has an appealing shape and small
dimensions, which facilitate easy transportation. It is safe
and reliable when in operation. It is driven by a single
phase electric motor via a V-belt. It is suitable for planing
wooden beams or boards and also for bevelling and
rebating.
PARTS LIST (Fig. 1+2)
A Control knob for adjustment of planing depth
B Indication of planing depth
C Protective guard
D Operating Switch
E Release Button
F Handle
G Cover, left
H Rebating depth stop with locking nut
K Planer shoe with V-groove
L Dustbag connection
SAFETY INSTRUCTIONS
The following pictograms appear throughout these
operating instructions:
Indicates danger of injury, risk to life and possible
damage to the appliance if these instructions are
not followed.
Indicates the presence of electrical current.
Read through these operating instructions carefully
before using the appliance. Become familiar with the
functions and method of operation. To ensure proper
operation, always maintain the appliance according to
the instructions. The operating instructions and
associated documents should always be kept close to the
appliance.
When using power tools, you must observe the
follwing basic safety precautions in order to ensure
protection from electric shocks, injury and fire.
Read and follow all the instructions before using this
power tool.
Look after the notes on safety.
ELECTRICAL SAFETY
Always check if your mains voltage corresponds
with the value on the type plate.
The machine has been double-insulated in
accordance with EN 50144; therefore, an
earth wire is not necessary.
When replacing old cables or plugs
Throw away old cables or plugs immediately as soon as
new ones have replaced these. It is dangerous to put the
plug of a loose cable into the socket outlet.
When using extension cables
Only use an approved extension cable that is suitable for
the machine’s power. The cores must have a diameter of
at least 1.5 mm
2
. When the extension cable is on a reel,
unroll the cable in its entirety.
SWITCH OFF THE MACHINE IMMEDIATELY
IN CASE OF
1. Malfunction in the mains plug, power cable or
damaging of cable.
2. Broken switch.
3. Smoke or stench of scorched insulation.
Voltage | 230 V~
Frequency | 50 Hz
Power consumption | 900 W
Number of revolutions, idle | 15000/min
Maximum planing width | 82 mm
Maximum planing depth | 2.5 mm
Maximum rebating depth | 18 mm
Weight | 3.5 kgs
LpA (sound pressure) | 87.9 dB(A)
LwA (sound capacity) | 100.9 dB(A)
Vibration value | 3.44 m/s
2
Ferm 3
SPARE PARTS LIST FP-900
REF NR DESCRIPTION FERM NR
3 BELT 406545
9 BEARING 6200 ZZ 806200
21 TILL 24 REBATING DEPTH STOP 406546
27 BEARING 608 ZZ 800608
30 ROTOR 406547
31 CARBON BRUSH (SET) 406548
34 BEARING 626 ZZ 800626
37 STATOR 406549
70 DUSTBAG 406565
41 TILL 43 UPPER PRESSING BAR COMPLETE 406531
44 PLANER BLADE PPA1003
45 LOWER PRESSING BLADE 406532
46 BEARING 608 ZZ 800608
54 TILL 57 SWITCH (SET) 406550
