10
EN
Adjusting the cutting angle
Fig. 2
Adjusting Mitre Angles
The mitre angle can be set between 45° left side
and 45° right side
- Loosen the locking knob (10).
- Turn the saw table left or right until the angle
indicator (23) indicates the required angle.
- Tighten the locking knob (10).
Pre-settings (quick settings) on the following
degrees: -45°, -40°, -35°, -30°, -25°, -20°, -15°,
-10°, -5°, 0°, 5°, 10°, 15°, 20°, 25°, 30°, 35°, 40°,
45°.
Adjusting Bevel Angles
Fig. 1 and 3
The bevel angle can be set between 0° and 45°.
Adjust sliding fence accordingly!
See chapter 3, sliding fence.
- Loosen the adjusting knob (9).
- Tilt the saw by using the handle until the angle
indicator (14) indicates the required angle.
- Tighten the adjusting knob (9).
Changing the carbon brushes
Fig. 2
- Disconnect the machine from the power
supply.
- Unscrew the two covers (4) on the front and
backside of the motor housing.
- Replace the carbon brushes with the exact
type of brushes.
- Tighten the covers (4) again.
Note: Always replace both carbon brushes at the
same time, never use a mixture of old and new
brushes.
Mounting the dust bag
Fig. 1
Press in the clamp of the dust bag (13) and slide
it onto the opening on the back of the machine.
The dust bag stays in place when you release the
clamp.
4. OPERATION
Using the mitre saw
Fig. 1
Before use, always check for faults or
defects!
• Setthedesiredsawingangleofthemachine.
• Puttheplugintothesocket.
• Fixthepieceofworkinplaceusingtheclamp
(7): make sure that the material is well clamped
in place!
• Holdthematerialtightlyontheleftsidewhile
making sure that you keep a safe distance
from the blade of the saw.
• Turnonthemachineusingtheswitch(1).
• Makesurethatthesawbladehasreachedfull
speed before allowing it to touch the piece of
work to be sawn.
• Useknob(3)toraisetheprotectivecoverlock.
• Nowbringthesawslowlydownwardssothat
the saw blade saws through the piece of work
and passes through the slot in the table. Do
not put any pressure on the saw. Give the
machine time to saw through the piece of
work.
• Bringthemachinegentlyupagainandswitch
it off by letting go of the switch (1).
Using the laser
Fig. 2
• Toswitchonthelaser,presstheon/offswitch
2.
• Toswitchoffthelaser,releasethe
on/off switch 2.
5. SERVICE AND MAINTENANCE
Always make sure that the machine is not
connected to the mains electricity when
you carry out any maintenance of the
mechanism.
Cleaning
Clean the machine housing regularly with a soft
cloth, preferably after each time you use the
machine. Make sure that the ventilation slots are
free of dust and dirt. For stubborn dirt use a soft
