Fermax DUOX plus 970049b - Page 25

Pag 25
Pag 25
6
CN3
OneToOne Module Connection
5
CN2
Individual connection buttons for continuous prole Cityline panel.
Select language for «open door»
message and voice assisted
conguration messages.
See CODING at the end of this
manual.
7
8
Adjust the audio:
“open door”
9
SPK
Loudspeaker connection
6
CN3
OneToOne Module Connection
5
CN2
Individual connection buttons for continuous prole Cityline panel.
Select language for «open door»
message and voice assisted
conguration messages.
See CODING at the end of this
manual.
7
8
Adjust the audio:
“open door”
9
SPK
Loudspeaker connection
